ELSW-J61C3-0LPGS-D6500
| Manufacturer | |
| Description | LED Uni-Color White 3-Pin SMT T/R High Power LEDs - White Cool White 6500K 150lm 700mA LED SHWO 3W HI PWR COOL WHT SMD LED, 3W,COOL WHITE,150LM |
| Category |
对参数有疑问？问 AI 助手
Business
| Product Category | High Power LEDs - White | Standard Package | Tape & Reel |
Compliance
| RoHS | RoHS Compliant | Tariff No | 85414010 |
Electrical
| Lamp Type | :- | Luminous Flux | 150(Min) lm |
| Viewing Angle | 120 ° | Current - Output | 700mA |
| Voltage - Supply | 3.55V (2.95 V ~ 4.15 V) | LED Forward Current | 700 mA |
| LED Forward Voltage | 3.4 V | Current Rating (Max) | 750mA |
| Power Dissipation (Max) | :3W | Lumens/Watt @ Current - Test | 60 lm/W |
| Flux @ 25degC, Current - Test | 150 lm (150 lm ~ 160 lm) | Flux @ 85degC, Current - Test | 131 lm |
| Current - DC Forward (If) (Max) | :750mA | ||
Mechanical
| Color | White | Width | 3.5 mm |
| Height | 1.5 mm | Length | 3.5 mm |
| Weight | 0.05 | LED Color | :Cool White |
| Packaging | Reel | Lamp Color | 6500 K |
| Lens Style | Circular | Mounting Type | Surface Mount |
| Mounting Style | Top Mount | Number of Pins | :2 |
| Package / Case | 3SMT | Material - Core | InGaN |
| Illumination Color | Cool White | CRI (Color Rendering Index) | 70 |
Product Info
| Type | Uni-Color | Series | :Shwo |
| CCT (K) | 6500K (6020K ~ 7050K) | Number of LEDs | 1 |
Environmental
| Operating Temperature | + 100 C | Thermal Resistance of Package | 6°C/W |
| Luminous Flux @ Current/Temperature | 158 lm | ||
