4N28
| Manufacturer | |
| Description | Optocoupler DC-IN 1-CH Transistor With Base DC-OUT 6-Pin PDIP Tube Transistor Output Optocouplers Optocouplers OPTOCOUPLER TRANS 5KVRMS 6DIP OPTOCOUPLER, TRANSISTOR O/P, DIP-6 |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 4N28EL | Product Category | Transistor Output Optocouplers |
| Standard Package | Rail / Tube | ||
Compliance
| RoHS | RoHS Compliant | Tariff No | 85414090 |
Electrical
| Output | NPN Phototransistor | Input Type | DC |
| Output Type | DC | Voltage Rating | :80V |
| Transistor Type | :NPN | Output Isolation | :Phototransistor |
| Number of Channels | 1 | LED Forward Voltage | 1.2 V |
| Voltage - Isolation | 5000 Vrms | Vce Saturation (Max) | 500mV |
| Voltage - Input (Min) | 80 V | Power - Average Forward | :200mW |
| Power Dissipation (Max) | 200 mW | Voltage Regulation - Load | 6 V |
| Current - Input Bias (Max) | 50 mA | Current Transfer Ratio (Min) | 10% @ 10mA |
| Voltage - Reverse Standoff (Typ) | 6 V | Voltage - Forward (Vf) (Max) @ If | 1.5 V |
| Current - Average Rectified (Io) (per Diode) | 60mA | ||
Mechanical
| Weight | 0.373 | Packaging | Tube |
| Mounting Type | Through Hole | Number of Pins | :6 |
| Optic Material | :DIP | Package / Case | 6PDIP |
Environmental
| Operating Temperature | -55 to 110 °C | ||
