B82790C475N265
| Manufacturer | |
| Description | Common Mode Filters / Chokes 4.7mH 200mA 510mohms Common Mode Chokes Dual 4.7mH 10kHz 200mA 510mOhm DCR SMD Blister T/R CHOKE COM MODE 4.7MH 200MA SMD INDUCTOR, 4.7MH, -30%+50%, 500MA, SMT-DATALINECHOKE2X4,7MH-30%/+50% |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Chokes | Other Names | 495-4415-2 |
| Part # Aliases | B82790C0475N265 | Product Category | Common Mode Filters / Chokes |
| Standard Package | 1,500 | Factory Pack Quantity | 1500 |
Compliance
| RoHS | RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 85045020 |
| Rad Hardened | No | Military Standard | Not Required |
| Material Flammability Rating | :UL94V-0 | ||
Electrical
| Current | 200mA | Core Type | :Common / Asymmetrical |
| Impedance | Not Required ohm | Tolerance | - 30 %, + 50 % |
| Inductance | 4.7 mH | Filter Type | Data, Signal Line |
| Range deg/s | :EPCOS - B82790C0 Series | Test Frequency | 0.01 MHz |
| Voltage Rating | 42VAC|80VDC | Inductance Range | :0.25µH |
| Current Rating - DC | :500mA | DC Resistance (DCR) | 510 mOhm |
| Voltage - Breakdown | 250VDC | Current Rating (Max) | 200 mA |
| DC Resistance (DCR) (Max) | :0.55ohm | Current - DC Forward (If) (Max) | 200 mA |
| Resistance - Initial (Ri) (Min) | 510 mOhms | ||
Mechanical
| Depth | 6 mm | Width | 6 mm |
| Height | 5.2 mm | Weight | 0.02 |
| Diameter | Not Required mm | Packaging | Reel |
| Height (Max) | 0.205" (5.20mm) | Core Material | Ferrite |
| Mounting Type | Surface Mount | Number of Pins | :4 |
| Package / Case | 4.9 mm | Length - Overall | 9 mm |
| Size / Dimension | 6 mm W x 9 mm L x 4.9 mm H | Termination Style | SMD/SMT |
| Dimensions - Overall | :7.1mm x 6mm x 4.9mm | ||
Product Info
| Type | Common Mode Choke, Ring Core | Series | B82790C0 |
| Failure Rate | Not Required | Configuration | Dual |
| Number of Lines | 2 | ||
Environmental
| Operating Temperature | -40°C ~ 125°C | ||
