B82731T2102A020
| Manufacturer | |
| Description | Fixed Inductors 10mH 1A -30%/+50% 21.5x13.5 Radial CHOKE, E CORE, 10MH, 1A EPCOS B82731T 系列 10 mH -30 → +50% 铁氧体 电源线扼流圈, 10kHz最大自谐振频率, 1A Idc, 630mΩ Rdc |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Chokes | Factory Pack Quantity | 576 |
Compliance
| RoHS | RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85045095 | ||
Electrical
| Core Type | :Power Line Choke | Tolerance | - 30 %, + 50 % |
| Inductance | 10 mH | Range deg/s | :EPCOS - B82731T Series |
| Inductance Range | :+50%, -30% | Current Rating - DC | :1A |
| Current Rating (Max) | 1 A | DC Resistance (DCR) (Max) | :0.63ohm |
| Resistance - Initial (Ri) (Min) | 630 mOhms | ||
Mechanical
| Width | 13.5 mm | Weight | 0.013 |
| Packaging | Tray | Core Material | :Ferrite |
| Number of Pins | :4 | Package / Case | 21.1 mm |
| Size / Dimension | 13.5 mm W x 21.5 mm L x 21.1 mm H | Termination Style | Radial |
Environmental
| Operating Temperature | - 40 C to + 125 C | ||
