点击放大查看
B84113H0000M116
| Manufacturer | |
| Description | FILTER LINE 250V 16A PANEL AC Power Line Filters 2-LEITER EMV-FILTER 16A 250V EPCOS SIFI-H 系列 16A 250 V 交流/直流, 50 至 60Hz 底盘安装 EMC 滤波器 , 带接线片，插片连接器接端 |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 495-4533 | Standard Package | 16 |
Compliance
| RoHS | RoHS Compliant | Approval Agency | cUL, ENEC, UL |
Electrical
| Current | 16A | Frequency | 50/60 Hz |
| Filter Type | Single Phase | Voltage Rating | 250 VAC, 250 VDC |
| Voltage - Rated | 250 V 交流/直流 | Current - Leakage | 2 uA |
| Voltage - Rated AC | 250V | Voltage - Rated DC | 250V |
| Current Rating (Max) | 16 A | Frequency - Operating | 50 ~ 60Hz |
Mechanical
| Depth | 51mm | Height | 43mm |
| Length | 91mm | Mounting Type | Chassis |
| Mounting Style | Screw | Terminal Style | 接线片，插片连接器 |
| Size / Dimension | 91 x 51 x 43mm | Termination Style | Quick Connect |
| Number of Positions | 1 | ||
Product Info
| Series | B84113H0000* | Function | Y |
| Applications | Medical | Configuration | Two Stage |
Environmental
| Operating Temperature | +40°C | ||
Documents & Media
PDF Document
PDF Document
