704.900.5
| Manufacturer | |
| Description | Momentary Action Modular Switch Contact Block CONTACT BLOCK, 1NO/1NC SWITCH CONTACT BLOCK Element,Switching;10A;VAC;SnapActionSwitchingElement;2;HardSilver Switch contact eao 14, 704.900.5, EAO 瞬时动作 接触装置, 使用于04 系列 |
| Category |
对参数有疑问？问 AI 助手
Business
| Lead Time | 60 Days | Subcategory | Contact Blocks |
Compliance
| RoHS | Not Applicable | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85365007 | ||
Electrical
| Voltage - Core | :500V | Voltage Rating | VAC |
| Number of Poles | :2 | Switch Function | SnapActionSwitchingElement |
| Current Rating (Max) | :10A | Current - Max/Contact | :10A |
| Switch Function/Rating | Momentary Action | Contact Rating (Current) | :10A |
| Connector - Voltage Input | :Screw | Voltage - Supply (Vcc/Vdd) | :24V |
Mechanical
| Weight | 0.028 | Contact Type | 1NormallyClosed+1NormallyOpen |
| Terminal Type | :Screw | Contact Material | HardSilver |
| Number of Contacts | 2 | Terminal Block Type | ScrewTerminal |
| Contact Layout, Typical | :1NO / 1NC | ||
Product Info
| For Use With/Related Products | :-000 A | ||
Environmental
| Operating Temperature | +55°C | ||
