TD1105A
| Manufacturer | |
| Description | SWITCH DETECTOR HORZ MT PCB T/H SWITCH DETECTOR HORZ MT PCB 30V Detector Switches 100mA 30VDC PC Mnt Series TD Detector Switches |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | EG2661 | Standard Pack | 200 |
| Standard Package | 200 | ||
Electrical
| Circuit | SPST-NO | Voltage Rating | 30V |
| Switch Function | Off-Mom | Current Rating (Max) | 100mA (DC) |
Mechanical
| Packaging | Bulk | Pretravel | 0.015" (0.4mm) |
| Actuator Type | Angled Toggle (Detector) | Mounting Type | Through Hole, Right Angle |
| Operating Force | 36gf | Termination Style | PC Pin |
Product Info
| Type | Switches | Series | TD |
| Card Standard | Detector Switch | Electrical Life | 50,000 Cycles |
| Operating Position | 0.197" (5.0mm) | ||
Environmental
| Operating Temperature | -20°C ~ 85°C | ||
