KAN1104RT
| Manufacturer | |
| Description | DIP Switches / SIP Switches 4 Position Recessed Low Prof, Half Pitch SW DIP SPST HALF PITCH 4 POS 24V DIP Switch Type: Half-Pitch / Low Profile Ratings: 25mA @ 24 VDC Number of Positions: 4 Termination: Gull Wing |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | EG4458 | Standard Pack | 75 |
| Standard Package | 75 | Factory Pack Quantity | 75 |
Electrical
| Circuit | SPST | Contact Resistance | initial 50m? typical @ 2-4 VCD, 100mA |
| Dielectric Strength | 500 V rms @ sea level between adjacent terminals | Insulation Resistance | 100 M? min. @ 500 VDC |
| Contact Rating @ Voltage | 0.025A @ 24VDC | ||
Mechanical
| Base Type | PPS UL94 V0, black finish | Packaging | Standard Tube w/ Top Tape Seal |
| Orientation | Top Actuated | Termination | Gull Wing |
| Contact Type | Copper alloy, gold finish | Actuator Type | Standard |
| Mounting Type | Surface Mount | Actuator Level | Recessed |
| Number of Positions | 4 | Shell Size - Insert | PPS UL94 V0, black finish |
| Contact Layout, Typical | SPST | Actuator Height off PCB, Vertical | Recessed |
Product Info
| Type | Half-Pitch / Low Profile | Series | KAN |
| Washable | Yes | Circuit Type | SPST |
| Card Standard | DIP Switch | ||
Environmental
| Ratings | 25mA @ 24 VDC | Seal Rating | Mylar, amber color |
| Mechanical Life | 2,000 make-and-break cycles, each circuit | Operating Temperature | -40° C to 85° C |
