B340-13-F
| Manufacturer | |
| Description | Diode Schottky 40V 3A 2-Pin SMC T/R SCHOTTKY-DIODE 3A 40V SMC DIODE SCHOTTKY 40V 3A SMC Schottky Diodes & Rectifiers 40V 3A DIODE, SCHOTTKY, 40V, 3A, SMC |
| Category |
对参数有疑问？问 AI 助手
Business
| MOQ | 3000 | Product | Schottky Diodes |
| Unit Pack | 3000 | Other Names | B340-FDICT |
| Product Category | Schottky Diodes & Rectifiers | Standard Package | Tape & Reel |
| Factory Pack Quantity | 3000 | ||
Compliance
| RoHS | Lead free by exemption / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85411000 | Rad Hardened | No |
| Leadfree Defin | RoHS-conform | ||
Electrical
| Speed | Fast Recovery = 200mA (Io) | U(RRM) | 40V |
| Unit (F) | 0.5V | Current - Test | 500 uA |
| Rectifier Type | Schottky Diode | Current - Surge | :100A |
| Voltage - Supply | 0.5 V | Capacitance @ Vr, F | 200pF @ 4V, 1MHz |
| Diode Configuration | :Single | LED Forward Voltage | 0.5 |
| Voltage - Input (Min) | 500mV @ 3A | Current - Output (Typ) | 3A |
| Voltage Regulation - Load | 40 V | Current - Peak Pulse (8/20us) | 100 A |
| Current - Reverse Leakage @ Vr | 500 uA | Voltage - DC Reverse (Vr) (Max) | 40V |
| Current - Average Rectified (Io) | 3 A | Voltage - Reverse Standoff (Typ) | 40 V |
| Current - LED Trigger (Ift) (Max) | :3A | Current - Continuous Drain (Id) @ 25degC | 3 A |
Mechanical
| Weight | 0.00021 | Packaging | Tape & Reel (TR) |
| Mounting Type | Surface Mount | Mounting Style | SMD/SMT |
| Number of Pins | :2 | Package / Case | 2SMC |
| Package Cooled | SMC | Material Finish | :MSL 1 - Unlimited |
| Number of Positions | 2 | Supplier Device Package | SMC |
Product Info
| Type | Schottky Diode | DELETED | Compliant |
| Matchcode | SS34 | Diode Type | Schottky |
| Configuration | Single | Standard Leadtime | 15 weeks |
Environmental
| Thermal Resistance | 90°C/W Ja | Operating Temperature | -55 to 125 °C |
| Operating Temperature - Junction | 150°C | ||
