AFB0648HH-A
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | 180 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Supplier Unconfirmed |
Electrical
| Noise | 40 dB(A) | Power (Watts) | 3.84W |
| Voltage Range | 20 ~ 56VDC | Voltage Rating | 48VDC |
| Current Rating (Max) | 0.080A | ||
Mechanical
| RPM | 5000 RPM | Weight | 0.176 lb (79.83g) |
| Air Flow | 27.6 CFM (0.780m³/min) | Fan Type | Tubeaxial |
| Termination | 2 Wire Leads | Bearing Type | Ball |
| Static Pressure | 0.294 in H2O (73.2 Pa) | Material - Blade | Plastic |
| Material - Frame | Plastic | Size / Dimension | Square - 60mm L x 60mm H x 25.4mm W |
Environmental
| Rated Life | 70000 hrs @ 40°C | Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) |
Documents & Media
PDF Document
Sourcing & traceability
- Datasheet
- AFB0648HH-A
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
