288T232R161A2
| Manufacturer | |
| Description | エンコーダ 16 COM (4 Pulses) 2 bit binary ROTARY ENCODER 2 BIT BIN CODE Encoders 16 COM (4 Pulses) 2 bit binary ENCODER, ROTARY, 2 BIT, BINARY |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Mechanical Encoders | Product Category | Encoders |
| Standard Package | 1 | ||
Compliance
| RoHS | RoHS Compliant | Tariff No | 85334010 |
Electrical
| Output | Quadrature | Resolution | 16 PPR |
| Output Type | Quadrature (Incremental) | Number of Channels | :2 |
Mechanical
| Weight | 0.001 | Orientation | Right Angle |
| Shaft Detail | Slotted | Actuator Type | 1/4" Dia Round End |
| Mounting Type | Panel Mount | Mounting Style | Panel |
| Shaft Diameter | 6.35 mm | Termination Style | Solder Lug |
| Length - Shaft and Bearing | 19.05 mm | Rotational Life (Cycles Min) | 50K |
Product Info
| Type | Incremental | Detent | Yes |
| Encoder Type | Mechanical | Built in Switch | No |
| Other Specifications | No Switch | Pulses per Revolution | 4 |
Environmental
| Operating Temperature | - 25 C to + 100 C | ||
