193-5MS
| Manufacturer | |
| Description | DIP Switches / SIP Switches 5 switch sections SPST Switch DIP OFF ON SPST 5 Piano 0.05A 24VDC Gull Wing 2.54mm SMD Tube SWITCH DIP 5POS SIDE ACT SMT |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | CT1935MS | Product Category | DIP Switches / SIP Switches |
| Standard Package | 35 | Factory Pack Quantity | 35 |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
Electrical
| Circuit | SPST | Voltage Rating | 24 |
| Current Rating (Max) | 0.05@24VDC | Switch Function/Rating | OFF ON |
| Contact Rating @ Voltage | 0.05A @ 24VDC | ||
Mechanical
| Seal | Epoxy | Depth | 11.23 |
| Height | 9.12 | Packaging | Tube |
| Orientation | Side Actuated | Contact Form | SPST |
| Pitch - Post | 2.54 mm | Actuator Type | Piano |
| Mounting Type | Surface Mount | Terminal Type | Gull Wing |
| Actuator Level | Raised | Contact Finish | Gold |
| Contact Material | Copper Alloy | Length - Overall | 14.88 |
| Termination Style | Solder Pad | Actuator Style/Size | Piano |
| Number of Positions | 5 | Switch Actuation Level | SPST |
Product Info
| Washable | No | Switch Type | DIP |
| Electrical Life | 7000 | ||
Environmental
| Operating Temperature | 85 | ||
