195-8MST
| Manufacturer | |
| Description | Switch DIP SPST 8 Piano 0.05A 24VDC PC Pins 2000Cycle 2.54mm Thru-Hole Tube Switch DIP SPST 8 Piano 0.05A 24VDC PC Pins 2000Cycles 2.54mm Thru-Hole Tube SWITCH SIDE ACTUATED 8 SEC 50V DIP Switches / SIP Switches 8 switch sections SPST Switch DIP SPST 8 Piano 0.05A 24VDC PC Pins 2.54mm Thru-Hole Tube |
| Category |
对参数有疑问？问 AI 助手
Business
| Product Category | DIP Switches / SIP Switches | Standard Package | Rail / Tube |
| Factory Pack Quantity | 25 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
Electrical
| Circuit | SPST | Voltage Rating | 24 V |
| Current Rating (Max) | 0.05@24VDC A | Contact Rating @ Voltage | 0.1A @ 50VDC |
Mechanical
| Seal | Tape/Epoxy | Depth | 10.92 |
| Height | 7.9 | Packaging | Tube |
| Orientation | Side Actuated | Contact Form | SPST |
| Pitch - Post | 2.54 mm | Actuator Type | Piano |
| Mounting Type | Through Hole | Terminal Type | PC Pins |
| Actuator Level | Raised | Contact Finish | Tin |
| Contact Material | Copper Alloy | Length - Overall | 22.5 |
| Termination Style | Through Hole | Actuator Style/Size | Piano |
| Number of Positions | 8 | Switch Actuation Level | SPST |
Product Info
| Washable | Yes | Switch Type | DIP |
| Electrical Life | 2000 | ||
Environmental
| Mechanical Life | 2000 | Operating Temperature | -40 to 85 °C |
