193-4MS
| Manufacturer | |
| Description | Switch DIP OFF ON SPST 4 Piano 0.05A 24VDC Gull Wing 2.54mm SMD Tube SWITCH DIP 4POS SIDE ACT SMT 50V DIP Switches / SIP Switches SPST 4 switch sections 193 Series Side Actuated SPST 4 Position Surface Mount DIP Switch |
| Category |
对参数有疑问？问 AI 助手
Business
| Product Category | DIP Switches / SIP Switches | Standard Package | Rail / Tube |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
Electrical
| Circuit | SPST | Voltage Rating | 24 V |
| Current Rating (Max) | 0.05@24VDC A | Switch Function/Rating | OFF ON |
| Contact Rating @ Voltage | 0.1A @ 50VDC | ||
Mechanical
| Seal | Epoxy | Depth | 11.23 |
| Height | 9.12 | Packaging | Tube |
| Orientation | Side Actuated | Contact Form | SPST |
| Pitch - Post | 2.54 mm | Actuator Type | Piano |
| Mounting Type | Surface Mount | Terminal Type | Gull Wing |
| Actuator Level | Raised | Contact Finish | Gold |
| Contact Material | Copper Alloy | Length - Overall | 12.34 |
| Termination Style | SMD/SMT | Actuator Style/Size | Piano |
| Number of Positions | 4 | Switch Actuation Level | SPST |
Product Info
| Washable | No | Switch Type | DIP |
| Electrical Life | 7000 | ||
Environmental
| Operating Temperature | -40 to 85 °C | ||
