CXE480D5
| Manufacturer | |
| Description | Solid State Relays - PCB Mount PCB SIP SSR 660Vac /5A, 15-32Vdc,ZC RELAY SSR 5A 480VAC SIP Relay SSR 15mA 32V DC-IN 5A 660V AC-OUT 4-Pin SIP SSR, 5A, 480VAC SSR,CXseries,SCR,zerocrossing,5A/660V Solid State Relay Control Voltage: 15-32 VDC Load Current: 5 Amps Load Voltage: 48-660 VAC Output Configuration: 1A SPST-NO Mounting: PC Board Crydom 5 A PCB（印刷电路板）安装安装 单刀单掷 固态继电器, SCR输出, 零交叉切换, 660 V rms |
| Category |
对参数有疑问？问 AI 助手
Business
| Lead Time | 56 Days | Other Names | CC1066 |
| Subcategory | Solid State Relay | Product Category | Solid State Relays - PCB Mount |
| Standard Package | 40 | Factory Pack Quantity | 1 |
Compliance
| RoHS | RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85364900 | Approval Agency | :CSA, VDE |
Electrical
| Output | SCR | Circuit | SPST-NO (1 Form A) |
| Slew Rate | :500V/µs | Output Type | AC, Zero Cross |
| Load Current | 5A | Switching Mode | :Zero Crossing |
| Voltage - Load | 48 ~ 660 V | Voltage Rating | :15V DC to 32V DC |
| Input Impedance | :1500ohm | Current - Output | :15mA |
| Voltage - Supply | 15 VDC to 32 VDC | Current - Leakage | :0.1mA |
| Dielectric Strength | :4000V | Voltage - Breakdown | :1200V |
| Current Rating (Max) | 5 A | Voltage - Input (Min) | 15 ~ 32VDC |
| Voltage - Supply (Max) | :32VDC | Voltage - Supply (Min) | 48 VAC to 660 VAC |
| Current Rating - Filter | :0.06A | Current - Quiescent (Max) | :0.06A |
| Current - Input Bias (Max) | 15 mA | Current - Average Rectified (Io) | :5A |
| Impulse Discharge Current (8/20us) | :260s | Voltage - Rated AC (Phase to Phase) | :660Vrms |
| Voltage - Rated AC (Phase to Ground/Neutral) | :48V | ||
Mechanical
| Depth | :7.6mm | Width | :43.1mm |
| Length | :25.4mm | Weight | 0.011 |
| Packaging | Bulk | Length - Pin | :7.6mm |
| Mounting Type | Through Hole | Mounting Style | Through Hole |
| Number of Pins | :4 | Package / Case | 4-SIP |
| Termination Style | Solder Pin | Contact Layout, Typical | :SPST-NO |
| Supplier Device Package | 4-SIP | ||
Product Info
| Series | CX | Relay Type | Relay |
| Product Type | PCB Mount | Control/Display Type | :DC |
Environmental
| Operating Temperature | :80°C | ||
Documents & Media
PDF Document
PDF Document
PDF Document
PDF Document
