C4OACA
| Manufacturer | |
| Description | I/O Modules 12-280 VAC Output OUTPUT MODULE AC C4 22MA 4-32VDC I/O Module Relays Output Module 32VDC 22mA 4000Vrms Thru-Hole/Plug-In I/O MODULE OUTPUT Mod.; Out Volt. 12-280 VAC; Inp.Volt. 4-32 VDC; 22 MA (MAX.); 8.33 msec |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 646-1051 | Product Category | I/O Modules |
| Standard Package | 25 | Factory Pack Quantity | 25 |
Compliance
| RoHS | RoHS Compliant | Standards | CE Marked, CSA Certified, RoHS Compliant |
| Tariff No | 85414090 | ||
Electrical
| Output | 12 to 280 VAC | Output Type | Analog |
| Output Range | 12 to 280 VAC | Turn On Time | 8.33ms |
| Voltage Rating | 4 VDC to 32 VDC | Current - Output | 22 mA |
| Delay Time - OFF | 8.33ms | Voltage - Supply | 4 to 32 VDC |
| Number of Outputs | :1 | Number of Channels | 1 |
| Analog Input:Output | :1 | Voltage - Isolation | 4000 V |
| Current - Input Bias | 22 mA | Current Rating (Max) | :22A |
| Voltage - Input (Min) | 12 ~ 280VAC (240VAC Nom) | Current - Input Bias (Max) | 22mA |
| Turn On / Turn Off Time (Typ) | 8.33 (Max.) ms | ||
Mechanical
| Color | Black | Width | :48.77mm |
| Length | :44.45mm | Weight | 0.032 |
| Mounting Type | PCB | Primary Material | Control |
| Size / Dimension | 47.49mmL×44.50mmW×8.64mmH | ||
Product Info
| Type | AC | Style | C4 |
| Features | Hold Down Screw, Fused, Status LED(s) | Manufacturer | C4 Series |
| Accessory Type | :AC Output Module | Connection Type | Board Mount |
| Module/Board Type | Output | For Use With/Related Products | :Crouzet Solid State Relays |
