RI-80SMD0515-G2
| Manufacturer | |
| Description | Magnetic / Reed Switches Ultra Long Gull Wing SWITCH REED MAG 5-15AT LNG-GULL REED SWITCH, SPST, 5MM, SMD |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 306-1146-1 | Standard Package | 7,000 |
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (16-Dec-2013) |
| Tariff No | 85364900 | ||
Electrical
| Circuit | SPST-NO | Power - Max | :5W |
| Switching Voltage | 175V | Contact Resistance | :160mohm |
| Current - Switching | 350mA | Voltage - Breakdown | :230V |
| Current - Max/Contact | :350mA | Insulation Resistance | :1000Gohm |
| Power - Average Forward | 5W | Switch Time (Ton, Toff) (Max) | :20 µs |
| Current - DC Forward (If) (Max) | :350mA | ||
Mechanical
| Weight | 0.00007 | Packaging | Tape & Reel (TR) |
| Body Material | :Glass | Mounting Type | PCB, Surface Mount |
| Terminal Type | :SMD | Number of Pins | :2 |
| Package / Case | :Glass | Length - Overall | :5mm |
| Material - Magnet | Not Specified | Termination Style | Gull Wing |
| Diameter - Outside | :1.8mm | Contact Layout, Typical | :SPST-NO |
| 1st Connector Mounting Type | :SMD | ||
Product Info
| Type | Glass Body | Series | :RI-80 |
| Must Release | 2 ~ 13AT | ||
Environmental
| Must Operate | 5 ~ 15AT | Operating Range | :5AT to 15AT |
| Operating Temperature | :125°C | ||
