CSS-1210TB
| Manufacturer | |
| Description | SWITCH SLIDE SPDT COMPACT SMD SW SLIDE SPDT COMPACT SMD 12V SWITCH,SLIDE,SMD |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 563-1091-1 | Standard Package | 1,900 |
Compliance
| RoHS | Lead free / RoHS Compliant | ||
Electrical
| Circuit | SPDT | Voltage Rating | 12VDC |
| Number of Poles | 1 | Switch Function | On-On |
| Dielectric Strength | 500VAC | Current Rating (Max) | 100mA |
| Contact Rating @ Voltage | 0.1A @ 12VDC | ||
Mechanical
| Orientation | Right Angle | Termination | SMD |
| Actuator Type | Standard | Mounting Type | Surface Mount |
| Mounting Style | PCB | Termination Style | Gull Wing |
| Number of Positions | 2 | Mounting Hole Diameter | 0.8mm |
Product Info
| Type | Slide | ||
Documents & Media
PDF Document
