8280-5SG-3DC
| Manufacturer | |
| Description | Standard Circular Connector MINI-CON CBL-CBL #20 CRIMP CONN RCPT 5POS CABLE SKT MINI-CONCABLE-CABLE#20CRIMP |
| Category |
Business
| Standard Package | 25 | Factory Pack Quantity | 25 |
Compliance
| RoHS | RoHS Compliant | ||
Electrical
| Voltage Rating | 600V | Current Rating (Max) | 4.8 A to 13 A |
Mechanical
| Packaging | Bulk | Wire Gauge | 24-20 |
| Orientation | Keyed | Termination | Crimp |
| Mounting Type | Free Hanging (In-Line) | Connector Type | Receptacle, Female Sockets |
| Contact Finish | Gold | Fastening Type | Bayonet Lock |
| Mounting Style | Wire | Termination Style | Crimp |
| 1st Contact Gender | Socket (Female) | Number of Contacts | 5 |
| Number of Positions | 5 | Shell Material, Finish | Nylon |
Product Info
| Series | Mini-Con-X | Product Type | Connectors |
Environmental
| Ingress Protection | Weathertight | Operating Temperature | -40°C ~ 115°C |
