CS53L21-CNZ
| Manufacturer | |
| Description | ADC Dual Delta-Sigma 96ksps 24-bit Serial 32-Pin QFN EP Rail IC ADC STEREO 24BIT 98DB 32QFN Audio A/D Converter ICs Low-Power Stereo ADC |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Audio ADCs | Product Category | Audio A/D Converter ICs |
| Standard Package | Rail / Tube | Factory Pack Quantity | 60 |
Compliance
| RoHS | Lead free / RoHS Compliant | ||
Electrical
| Interface | Serial | Input Type | Voltage |
| Resolution | 24 Bit | Data Interface | Serial |
| Input Polarity | Bipolar | Voltage Rating | +/- 0.702 V, +/- 0.975 V |
| Data Rate (Max) | 96 KSPs | Voltage - Supply | 1.65 V ~ 1.89 V, 2.37 V ~ 2.63 V |
| Resolution (Bits) | 24 b | Sampling Frequency | 96 ksps |
| Number of ADCs / DACs | 2 | Voltage Supply Source | Analog and Digital |
| Power - Average Forward | 60 mW | Sampling Rate (Per Second) | 96k |
| S/N Ratio, ADCs / DACs (db) Typ | Yes | ||
Mechanical
| Height | 0.95 mm | Length | 5 mm |
| Packaging | Tray | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Package / Case | 32QFN EP |
| Supplier Device Package | 32-QFN (5x5) | ||
Product Info
| Type | ADC, Audio | Series | CS53L21 |
| Architecture | Delta-Sigma | Manufacturer | Cirrus Logic |
| Number of A/D Converters | 6 | ||
Environmental
| Operating Temperature | -10°C ~ 70°C | ||
