CS4525-CNZ
| Manufacturer | |
| Description | Digital Audio Amplifier with ADC 48-Pin QFN EP Rail IC AMP AUDIO PWR 30W QUAD 48QFN 9mm CS4525-CNZ, Audio Amplifier Class-D stereo +70°C 48-Pin QFN Audio Amplifiers PWM controller+ power stage |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Class-D | Product Category | Audio Amplifiers |
| Standard Package | Rail / Tube | Factory Pack Quantity | 260 |
Compliance
| RoHS | Lead free / RoHS Compliant | ||
Electrical
| PSRR | 40 dB to 60 dB | Noise | 10 % |
| Impedance | 4 Ohms, 6 Ohms, 8 Ohms | Output Type | 2-Channel (Stereo) or 4-Channel (Quad) |
| Input Signal | Single Ended | Output Power | 30 W |
| Output Signal | Differential | Current - Output | 54 mA |
| Current - Supply | 54 mA | Voltage - Supply | 8 V ~ 18 V |
| Power Supply Type | Single | Number of Channels | 2 |
| Power - Average Forward | 180 mW | Power Dissipation (Max) | 180 mW |
| Max Output Power x Channels @ Load | 30W x 1 @ 4 Ohm; 15W x 2 @ 8 Ohm | ||
Mechanical
| Width | 9mm | Height | 0.85mm |
| Length | 9mm | Packaging | Tube |
| Mounting Type | Surface Mount | Mounting Style | SMD/SMT |
| Package / Case | 48QFN EP | Package Cooled | QFN |
| Size / Dimension | 9 x 9 x 0.85mm | Number of Positions | 48 |
| Supplier Device Package | 48-QFN-EP (9x9) | Load Side Wire/Stud Size | 8 Ohms, 4 Ohms |
Product Info
| Type | Class D | Class | Class-D |
| Series | CS4525 | Features | ADC, Depop, I²C, I²S, Mute, PWM, Short-Circuit and Thermal Protection, Volume Control |
| Manufacturer | Cirrus Logic | Amplifier Type | Class-D |
| RF Family/Standard | CS4525 | Application Specifics | Desktop Computer, Digital Powered Speaker, Integrated Digital TV, Mini/Micro Shelf System, Monitor, Portable Docking Station |
Environmental
| Operating Temperature | 0 to 70 °C | ||
