CS4412A-CNZ
| Manufacturer | |
| Description | Audio Amplifiers 30W Qd Hlf-Bridge Dig. Amp Pwr Stage IC AMP AUDIO PWR 30W QUAD 48QFN IC, POWER STAGE, SMD, QFN-48, 4412 |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 598-1653 | Standard Package | 260 |
Compliance
| Tariff No | 85423300 | ||
Electrical
| Impedance | :4ohm | Output Type | 2-Channel (Stereo) or 4-Channel (Quad) |
| Output Power | :30W | Power - Output | :30W |
| Voltage - Supply | 8 V ~ 18 V | Number of Channels | :4 |
| Impedance (Max) (Zzt) | :4ohm | Power - Average Forward | :30W |
| Max Output Power x Channels @ Load | 30W x 1 @ 4 Ohm; 15W x 2 @ 8 Ohm | ||
Mechanical
| Weight | 0.0008 | Packaging | Tube |
| Termination | :SMD | Mounting Type | Surface Mount |
| Number of Pins | :48 | Package / Case | 48-QFN |
| Material Finish | :MSL 2 - 1 year | Supplier Device Package | 48-QFN-EP (9x9) |
Product Info
| Type | Class D | Features | Depop, Short-Circuit and Thermal Protection, Standby |
| Base Unit | :4412 | Amplifier Type | :D |
| Other Specifications | :0.1% @ 1W, 4ohm, VD=3.3V | ||
Environmental
| Operating Temperature | :-10°C | ||
Documents & Media
PDF Document
