CS4272-CZZ
| Manufacturer | |
| Description | Audio Codec 2ADC / 2DAC 24-Bit 28-Pin TSSOP Tube IC CODEC AUD 24BIT 114DB 28TSSOP CS4272-CZZ, Audio Codec 2 (ADC), 2 (DAC)-channel 24bit- 192ksps Serial-I2S, Serial-SPI 28-Pin TSSOP Interface - CODECs Stereo Audio CODEC 114 dB 192 kHz CS4272-CZZ D/A converter; Serial; 2.37÷5.25VDC; TSSOP28 立体声通道 192ksps 24bit 音频编解码器, 串行I2S、串行SPI接口, 28针 TSSOP封装 |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Audio CODECs | Product Category | Interface - CODECs |
| Standard Package | Rail / Tube | Factory Pack Quantity | 50 |
Compliance
| RoHS | Lead free / RoHS Compliant | ||
Electrical
| Noise | - 100 dB ADC/- 100 dB DAC | Interface | Serial-I2S, Serial-SPI |
| Resolution | 24 bit | Input Range | 2 |
| Sigma Delta | Yes | Power - Input | 单 |
| Data Interface | PCM, Serial | Voltage Rating | 3.3 V, 5 V |
| Data Rate (Max) | 192 kSPs | Number of DAC's | 2 |
| Voltage - Supply | 3.3|5 V | Number of Outputs | 2 |
| Power Supply Type | Analogue, Digital | Resolution (Bits) | 24 Bit |
| Number of Channels | 2ADC /2 DAC | Sampling Frequency | 192 ksps |
| Number of ADCs / DACs | 2 / 2 | Voltage - Supply, Analog | 4.75 V ~ 5.25 V |
| Voltage - Supply, Digital | 3.1 V ~ 5.25 V | Sampling Rate (Per Second) | 192ksps |
| Dynamic Range, ADCs / DACs (db) Typ | 114 / 114 | ||
Mechanical
| Width | 4.4mm | Height | 0.9mm |
| Length | 9.7mm | Weight | 9.75 g |
| Bandwidth | 10 Hz to 20 kHz | Packaging | Tube |
| Mounting Type | Surface Mount | Mounting Style | SMD/SMT |
| Number of Pins | 28 | Package / Case | 28TSSOP |
| Package Cooled | TSSOP | Package Quantity | TSSOP |
| Size / Dimension | 9.7 x 4.4 x 0.9mm | Number of Positions | 28 |
| Supplier Device Package | 28-TSSOP | ||
Product Info
| Type | General Purpose | Series | CS4272 |
| Function | Y | Manufacturer | Cirrus Logic |
| Number of Units | 1 | Number of A/D Converters | 2 |
Environmental
| Operating Temperature | -10°C ~ 70°C | ||
