DB-24659-32

Manufacturer	Cinch Connectors
Description	D-Sub Backshells 25C DEEP STRT CLMP CONN BACKSHELL DB25 METAL JUNCTION SHELL, SIZE DB, STEEL Hood;D-Sub;25Pos;StraightExit;DBSeries;Metal;25.40mmCblDia;One-Piece
Category	Connector SolutionsD-Sub ConnectorsD-Sub Connectors

对参数有疑问？问 AI 助手

Business

Product Category	D-Sub Backshells	Standard Package	1,000
Factory Pack Quantity	1000

Compliance

RoHS

RoHS Compliant

Tariff No

85045020

Mechanical

Color	Yellow	Weight	0.014
Plating	Zinc, Yellow Chromate Finish	Material	Metal, Carbon Steel
Shielding	Unshielded	Cable Exit	180°
Cable Type	Flat	Shell Size	B
Shell Plating	Zinc	Cable Diameter	25.40mm
Cable Material	Zinc-PlatedSteelwithYellowChromateFinish	Screw Material	Zinc-PlatedSteelwithYellowChromateFinish
Shell Material	Steel	Material - Body	:Steel
Number of Positions	25	Plating - Thickness	Zinc
Shell Size - Insert	:DB	Exterior Housing Material	:Steel
Backshell Material, Plating	Metal

Product Info

Series	:DB	Features	One-Piece
Hardware	Cable Clamp	Manufacturer	DBSeries
Accessory Type	One Piece Backshell

Documents & Media

PDF Document

Dx-246xx-3x

PDF Document

660145.pdf

PDF Document

1195249116-DX-246XX-3X.PDF
