CU103603
| Manufacturer | |
| Description | Board Mount Motion & Position Sensors 45 Degree Sense Rg AN820003 w/Magnet RotaryPosition Sensor 16V SENSOR MAGN PROG 5VDC RANGE 45 RotaryPosition Sensor 16V Product Highlights:Rugged design with current switching up to 20 amps2-color molded button available for maximum visibilityLighted and non-lighted versionsSplash-proof option availableAvailable in a wide variety of colorsFits to 3 panel cut-out widths SENSOR, MAGNETIC POSITION, AN8 SERIES SENSOR Sensor,MagnetAssembly,5VDC,Range45 |
| Category |
对参数有疑问？问 AI 助手
Business
| Lead Time | 126 Days | Subcategory | Angular and Linear Position Sensor |
| Product Category | Board Mount Motion & Position Sensors | Standard Package | 25 |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Supplier Unconfirmed |
| Tariff No | 90318038 | ||
Electrical
| Linearity | ±2% | Output Type | Analog |
| Sensor Type | Angular, Rotary | Sensing Distance | 5 mm |
| Voltage - Supply | 5V | Voltage - Supply (Min) | 16 |
Mechanical
| Width | 48.3 | Weight | 0 |
| Packaging | 4.5 | Mounting Type | Screw |
| Length - Overall | 57.33 | ||
Product Info
| Type | Rotary | Accessory Type | :Magnet Assembly |
| Other Specifications | 45° | For Use With/Related Products | :AN820003 Series Sensors |
Environmental
| Operating Temperature | -40°C ~ 150°C | ||
