CRE22F4DBBNE
| Manufacturer | |
| Description | Rocker Switches & Paddle Switches SPST ON-OFF BLK 20A ON OFF Switch Rocker ON OFF SPST Quick Connect Curved Rocker 20A 250VAC 559.27VA 100000Cycles SWITCH ROCKER SPST 20A 125V Switch Rocker ON OFF SPST Quick Connect Curved Rocker 20A 250VAC 559.27VA 100000Cycle Switch Rocker ON OFF SPST Quick Connect Curved Rocker 20A 250VAC 559.27VA 100000Cycle Product Highlights:Rugged design with current switching up to 20 amps2-color molded button available for maximum visibilityLighted and non-lighted versionsSplash-proof option availableAvailable in a wide variety of colorsFits to 3 panel cut-out widths SWITCH,POWERROCKER |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | CH801 | Standard Package | 100 |
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
Electrical
| Circuit | SPST | Power - Rated | 559.27@(CSA/UL) |
| Voltage Rating | 125V | Switch Function | On-Off |
| Current Rating (Max) | 20A (AC) | Voltage - Input (Min) | 250 |
| Switch Function/Rating | ON OFF | ||
Mechanical
| Depth | 16.5 | Height | 37.03 |
| Packaging | Bulk | Mounting Type | Panel Mount |
| Terminal Type | Quick Connect | Contact Material | Silver Alloy |
| Length - Overall | 31.8 | Actuator Material | Nylon 66 |
| Termination Style | Quick Connect - 0.250" (6.3mm) | Actuator Style/Size | Curved Rocker |
| Color - Actuator/Cap | Black, Red | Switch Actuation Level | SPST |
| Panel Cutout Dimensions | Rectangular - 28.50mm x 12.10mm | Material - Housing & Prism | Nylon 66/Nylon 66 |
Product Info
| Features | Two-Tone Rocker | Electrical Life | 6,000 Cycles |
| Actuator Marking | On - Off, Vertical | ||
Environmental
| Mechanical Life | 100,000 Cycles | Operating Temperature | -20°C ~ 85°C |
