ZICM2410P0-1C-SN-B
| Manufacturer | |
| Description | Zigbee / 802.15.4 Modules 20dBm OP u.FL Conn SNAP Software MODULE MESHCONNECT TXRX W/SNAP |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | 28 | ||
Compliance
| RoHS | RoHS Compliant | ||
Electrical
| Data Rate | 250 kbps | Frequency | 2.4GHz |
| Interface | I2S, SPI, UART | Memory Size | 96kB Flash, 8 kB RAM |
| Sensitivity | - 97 dBm | Output Power | 6 dBm |
| Sensing Range | 2000 ft | Data Interface | Pads for Pins |
| Power - Output | 6dBm | Data Rate (Max) | 250kbps |
| Current - Supply | 35 mA | Voltage - Supply | 2.1 V to 3.3 V |
| Current - Receiving | 35mA | Current - Transmitting | 44mA |
| Current - Supply (Main IC) | 44 mA | Frequency Bands (Low / High) | 2.405 GHz to 2.48 GHz |
Mechanical
| Packaging | Bulk | Package / Case | Module |
| Size / Dimension | 1.4 in x 1 in x 0.195 in | Antenna Connector | U.FL |
Product Info
| Applications | Home/Building Automation, Industrial Control | Modulation or Protocol | 802.15.4 Zigbee |
Environmental
| Mechanical Life | Verify Status with Factory: Lifecycle information is unclear. Obtain a quote to verify the availability of this part number from the manufacturer. | Operating Temperature | + 85 C |
