RSGD4012F0VD20
| Manufacturer | |
| Description | SOFTSTART 400vac 3PH 12A Soft starter, RSGD4012F0VD20, Carlo Gavazzi Carlo Gavazzi RSGD 系列 12 A 软启动器, IP20, 3 千瓦 |
| Category |
对参数有疑问？问 AI 助手
Electrical
| Power - Rated | 3 kW | Power - Output | 5.5 kW |
| Voltage Rating | 400 V ac | Load Capacitance | 3 A@ 230 VAC |
| Voltage - Supply | 24 VAC/DC | Voltage - Start Up | 0...85 % |
| Current Rating (Max) | 12 A | Frequency - Output 1 | 3 |
| Voltage - Supply (Min) | 220...400 VAC | Phase Noise Typ (dBc/Hz) | 3 |
| Voltage - Protection Level (VP) (2416) | IP 20 | Voltage - Collector Emitter Breakdown (Max) | 24 V 交流/直流 |
Mechanical
| Width | 45mm | Start Type | 1...20 s |
| Acceleration | 0...20 s | Depth - Overall | 109.8mm |
| Width - Overall | 45mm | Length - Overall | 125mm |
Product Info
| Series | RSGD | Control/Display Type | 24 V ac/dc |
Environmental
| Seal Rating | IP20 | Ingress Protection | IP20 |
| Operating Temperature | +60°C | ||
