RGS1A60A90KKE
| Manufacturer | |
| Description | SSR 600vac 90A AC/DC Control 1PH-E-SSRLY-IN:ACSRW-OUT:ZC600VAC90A1200VSRW Carlo Gavazzi 90 A 底盘安装安装 单刀单掷 固态继电器, 零交叉切换, 600 V 交流 |
| Category |
对参数有疑问？问 AI 助手
Electrical
| Voltage - Supply | 42 → 600V 交流 | Battery Pack Voltage | 42 V ac |
| Current Rating (Max) | 90 A | Minimum Load Required | 400 mA |
| Voltage - Input (Min) | 190 V dc, 275 V ac | Voltage - Supply (Min) | 20 V ac, 24 V dc |
| Input Logic Level - High | 20 → 275 V 交流，24 → 190 V 直流 | Voltage - Limiting (Max) | 600 V 交流 |
| Current - Off State (Max) | 3 mA | Current - Quiescent (Max) | 400 mA |
Mechanical
| Depth | 51mm | Height | 90mm |
| Length | 17.8mm | Mounting Type | Screw Mount |
| Terminal Type | Screw | Package / Case | Module |
| Size / Dimension | 17.8 x 51 x 90mm | Termination Style | 螺丝 |
| Minimum Working Height | 42V 交流 | Contact Layout, Typical | SPST |
Product Info
| Function | Y | Switch Type | Zero Crossing |
Environmental
| Operating Temperature | -40 → +80°C | ||
