K5V1RD43T
| Manufacturer | |
| Description | Tactile Switches Switch Tact Spdt 400Gf Red Ra Th SWITCH TACTILE SPDT 0.1A 32V Switch Tactile N.O./N.C. SPDT Round Button PC Pins 0.1A 32VDC 1VA 25000Cycles 4N Thru-Hole Tray PCB Switch without snap-in 0.02 VDC ...32 VDC 0.1 ...100 mA LED red, K5V1RD43T, C&K |
| Category |
对参数有疑问？问 AI 助手
Business
| Part # Aliases | Y71243251FP | Product Category | Tactile Switches |
| Standard Package | 60 | Factory Pack Quantity | 60 |
Compliance
| RoHS | RoHS Compliant | ||
Electrical
| LED | red | Circuit | SPDT |
| Power - Rated | 1 VA | Voltage Rating | 32 V |
| Number of Poles | 1 | Switch Function | Momentary |
| Current Rating (Max) | 100 mA | Contact Rating @ Voltage | 0.1A @ 32VDC |
Mechanical
| Outline | 9.45mm x 8.00mm | Packaging | Bulk |
| Contact Form | SPST | Actuator Type | Round |
| Mounting Type | Through Hole, Right Angle | Switch Travel | 1.20mm |
| Contact Finish | Silver | Mounting Style | SMD/SMT |
| Actuation Force | 4 N | Operating Force | 4 N |
| Contact Material | Au plated | Termination Style | Solder |
| Color - Background | transparent | Illumination Color | Translucid Red |
| Actuator Orientation | Side Actuated | Illumination Type, Color | LED, Red |
| Actuator Height off PCB, Vertical | 12.40mm | ||
Product Info
| Series | K5V | Features | Tactile Feedback |
| Description | without snap-in | Switch Type | Momentary function |
| Illumination | Illuminated | ||
Environmental
| Mechanical Life | 25,000 Cycles | Ingress Protection | IP40 |
| Operating Temperature | - 40 C to + 85 C | ||
