K5V1RD43G
| Manufacturer | |
| Description | SWITCH TACTILE SPDT 0.1A 32V SWITCH, SMD, R/A, SPDT, RED |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 401-1663-2 | Standard Package | 330 |
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85365007 | Material Flammability Rating | :UL94 HB |
Electrical
| Circuit | SPDT | Voltage - Core | :-00V |
| Switch Function | On-Mom | Current - Switching | :0.1mA |
| Current - Max/Contact | :100mA | Voltage - Supply (Min) | :20mV |
| Contact Rating @ Voltage | 0.1A @ 32VDC | Connector - Voltage Input | :Solder |
| Voltage - Supply (Vcc/Vdd) | :32V | Current - DC Forward (If) (Max) | :100mA |
Mechanical
| Depth | :10.1mm | Width | :8mm |
| Length | :9.45mm | Weight | 0.0044 |
| Outline | 9.45mm x 8.00mm | Material | :Thermoplastic |
| LED Color | :Red | Packaging | Tape & Reel (TR) |
| Actuator Type | Translucent | Mounting Type | Surface Mount, Right Angle |
| Switch Travel | 1.20mm | Terminal Type | :SMD |
| Operating Force | 400gf | Termination Style | Gull Wing |
| Color - Connectors | :Translucid | Number of Positions | :25000 |
| Actuator Orientation | Side Actuated | Color - Actuator/Cap | :Transparent |
| Switch Actuation Level | :Side | Contact Layout, Typical | :SPDT |
| Illumination Type, Color | LED, Red | Actuator Height off PCB, Vertical | 12.40mm |
Product Info
| Series | :K5V | Features | Tactile Feedback |
| Illumination | Illuminated | ||
Environmental
| Mechanical Life | 25,000 Cycles | Switching Cycles | :25000 |
| Ingress Protection | IP40 | Operating Temperature | -40°C ~ 85°C |
