E101MD1CBE
| Manufacturer | |
| Description | Switch Toggle ON None ON SPDT Round Toggle PC Pins 20VAC 20VDC 0.4VA PC Mount Toggle SWITCH TOGGLE SPDT 0.4VA 20V Toggle Switches SPDT ON-NONE-ON |
| Category |
对参数有疑问？问 AI 助手
Business
| MOQ | 50 | Lead Time | 49 Days |
| Unit Pack | 1 | Subcategory | Switch Toggle |
| Product Category | Toggle Switches | Standard Package | Bulk |
| Factory Pack Quantity | 1 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | ||
Electrical
| Circuit | SPDT | Power - Rated | 0.4@20VAC 20VDC VA |
| Voltage Rating | 20 V | Switch Function | On-On |
| Voltage - Rated AC | 20V VAC | Current Rating (Max) | 0.4VA (AC/DC) |
| Switch Function/Rating | ON None ON | Voltage - DC Spark Over (Nom) | 20V VDC |
Mechanical
| Depth | 6.6 mm | Height | 24.41 mm |
| Packaging | Bulk | Contact Form | SPDT |
| Actuator Type | Standard Round | Mounting Type | PC Mount |
| Terminal Type | PC Pins | Bushing Thread | Unthreaded |
| Contact Finish | Gold/Nickel | Mounting Style | Through Hole |
| Actuator Length | 7.62mm | Contact Material | Copper Alloy |
| Length - Overall | 12.7 mm | Actuator Material | Brass, Chrome Plated |
| Termination Style | PC Pin | Actuator Style/Size | Toggle |
| Switch Actuation Level | SPDT | ||
Product Info
| Type | Sealed Miniature | Series | E |
| Features | Epoxy Sealed Terminals | Illumination | Non-Illuminated |
| Electrical Life | 40,000 Cycles | ||
Environmental
| Seal Rating | Sealed | Ingress Protection | IP57 - Dust Protected, Waterproof |
| Operating Temperature | -30 to 85 °C | Operating Temperature - Junction | 85C |
