BD12AV
| Manufacturer | |
| Description | Switch DIP OFF ON SPST 12 Extended Slide 0.1A 25VDC PC Pins 10000Cycle/SwitchCycle 2.54mm Thru-Hole Tube Switch DIP OFF ON SPST 12 Extended Slide 0.1A 25VDC PC Pins 10000Cycles/SwitchCycles 2.54mm Thru-Hole Tube DIP / Rotary DIP SWITCH DIP R/A SLIDE 12POS 5V C&K DIP SWITCH |
| Category |
对参数有疑问？问 AI 助手
Business
| MOQ | 150 | Unit Pack | 15 |
| Standard Package | Rail / Tube | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
Electrical
| Circuit | SPST | Voltage Rating | 25 V |
| Current Rating (Max) | 0.1@5VDC A | Switch Function/Rating | OFF ON |
| Contact Rating @ Voltage | 0.1A @ 5VDC | ||
Mechanical
| Seal | Tape | Depth | 11.69 |
| Height | 9.65 | Packaging | Tube |
| Orientation | Side Actuated | Pitch - Post | 2.54 |
| Actuator Type | Standard | Mounting Type | Through Hole |
| Terminal Type | PC Pins | Actuator Level | Raised |
| Contact Material | Gold/Nickel/Phosphor Bronze | Length - Overall | 32.51 |
| Actuator Style/Size | Extended Slide | Number of Positions | 12 |
| Switch Actuation Level | SPST | Actuator Height off PCB, Vertical | Raised |
Product Info
| Type | Switches | Series | BD |
| Washable | Yes | Circuit Type | SPST |
| Electrical Life | 10000/Switch | ||
Environmental
| Mechanical Life | 10000/Switch | Operating Temperature | -40 to 85 °C |
