1.15108.3510000
| Manufacturer | |
| Description | Switch Push Button N.O./N.C. SPDT Flush Square Button 4A 250VAC 220VDC Solder Panel Mount Pushbutton Switches SWITCH PUSH DPST 4A 250V |
| Category |
对参数有疑问？问 AI 助手
Business
| Part # Aliases | 1.15108.351/0000 | Standard Package | Bulk |
| Factory Pack Quantity | 10 | ||
Compliance
| RoHS | RoHS Compliant | EU RoHS | Supplier Unconfirmed |
Electrical
| Circuit | DPST (1-NO, 1-NC) | Voltage Rating | 220 V |
| Switch Function | Latching | Current Rating (Max) | 4@250VAC A |
| Voltage - Input (Min) | 250 V | Switch Function/Rating | N.O./N.C. |
Mechanical
| Depth | 18 | Height | 49 |
| Packaging | Bulk | Contact Form | 1 NC - 1 NO |
| Actuator Type | Flush | Mounting Type | Panel Mount |
| Terminal Type | Solder | Contact Finish | Tin |
| Mounting Style | Snap In | Contact Material | Silver |
| Length - Overall | 18 | Termination Style | Solder |
| Actuator Style/Size | Flush Square Button | Switch Actuation Level | SPDT |
| Panel Cutout Dimensions | Circular - 16.20mm Dia | Illumination Type, Color | Filament Lamp |
| Material - Housing & Prism | N/A/Polyamide 6 | ||
Product Info
| Type | Standard, Illuminated | Series | LUMOTAST 75 |
| Illumination | Illuminated | Electrical Life | 60000 |
Environmental
| Ingress Protection | IP40 | Operating Temperature | -25 to 55 °C |
