Business
| Product Category | Standard Circular Connector | Standard Package | 25 |
| Factory Pack Quantity | 25 | ||
Compliance
| RoHS | Compliant | Tariff No | 85366990 |
| Approval Agency | :CSA, UL, VDE | Material Flammability Rating | :UL94V-0 |
Electrical
| Voltage Rating | 50 V ac/dc | Voltage - Working | :50V |
| Contact Resistance | :5mohm | Current Rating (Max) | 5A |
| Insulation Resistance | :100Mohm | ||
Mechanical
| Weight | 0.02006 | Packaging | Bulk |
| Wire Gauge | 22-26 | Orientation | Keyed |
| Shell Style | Receptacle | Termination | Crimp, Solder |
| Contact Type | Crimp and Solder Cup | Mounting Type | Free Hanging (In-Line) |
| Angle of Throw | Straight | Cable Diameter | 6-8mm |
| Connector Type | Receptacle for Female Contacts | Contact Finish | Gold over Nickel |
| Fastening Type | Threaded | Mounting Style | Free Hanging |
| Insertion Angle | :- | Material - Body | :Nylon (Polyamide) |
| Contact Material | Copper Alloy | Housing Material | GlassFilledPolyamide |
| Primary Material | Sealed | Termination Style | Crimp / Solder |
| 1st Contact Gender | Female | Color - Connectors | :Black |
| Number of Contacts | 12 | Dielectric Material | Polyamide |
| Number of Positions | 12 | Shell Size - Insert | :- |
| Shell Material, Finish | Polyamide, Glass Filled | 1st Connector Mounting Type | :Cable |
| Diameter - Outside, Non-Expanded | :8.1mm | ||
Product Info
| Note | Contacts Not Provided | Type | CableSocket |
| Gender | :Socket | Series | Buccaneer |
| Product Type | Connectors | ||
Environmental
| NEMA Frame Size | :IP68 | Ingress Protection | IP68/69K - Dust Tight, Waterproof |
| Operating Temperature | +70°C | ||
