MPI001/28/RD/24
| Manufacturer | |
| Description | SWITCH PUSH SPST-NO 0.05A 24V Switch,p/b,vandal res,dot red,24V,IP66 Bulgin IP66 SP - 常开 面板安装 瞬间 照明 按钮开关, 50 mA |
| Category |
对参数有疑问？问 AI 助手
Electrical
| LED | 红色 | Switch Function | 瞬间 |
| Current Rating (Max) | 50 mA @ 24 V 直流 | Switch Function/Rating | Momentary |
| Contact Rating (Current) | 50 mA | ||
Mechanical
| LED Color | Red | Case Color | Silver |
| Light Color | 是 | Actuator Type | Button |
| Mounting Type | Panel Mount | Terminal Type | Tab |
| Connector Type | 翼片 | Contact Material | Gold Plated |
| Panel Cutout Shape | 19.2mm | Exterior Housing Color | 银色 |
| Contact Layout, Typical | SP-NO | Panel Cutout Dimensions | 19.2mm |
Product Info
| Illumination | Yes | ||
Environmental
| Seal Rating | IP66 | Ingress Protection | IP66 |
| Operating Temperature | +70°C | ||
