FX0430/63
| Manufacturer | |
| Description | Fuse Holders SNAP PANEL 6.3MM TAB FUSE HLDR CART 250V 10A PNL MNT Drawer type snap-in fuse holder,5x20mm FUSE HOLDER, SNAP IN, 20X5MM Bulgin FX0430 系列 16A 手动帽盖 面板固定熔断器座，适用于5 x 20mm熔断器, PC3 Fuse Holder SNAP PANEL 6.3MM TAB |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Fuse Holders | Product Category | Fuse Holders |
| Standard Package | 1 | Factory Pack Quantity | 100 |
Compliance
| RoHS | RoHS Compliant | SVHC | :No SVHC (19-Dec-2012) |
| Tariff No | 85369010 | Protection | PC3 |
Electrical
| Voltage | 250V | Voltage Rating | 250 V |
| Number of Poles | 1 | Voltage - Breakdown | :2kV |
| Current Rating (Max) | 10 A | Load Side Connections Per Pole | :Solder Lug |
Mechanical
| Depth | :33.20mm | Width | :35.14mm |
| Length | :11.60mm | Weight | 0.008 |
| Material | :Phosphor bronze, nickel plated | Shaft Detail | Captive Drawer |
| Body Material | Nylon | Mounting Type | Panel Mount |
| Terminal Type | :Quick connect push-on terminals | Contact Finish | Tin |
| Mounting Style | Panel | Fuseholder Type | Holder |
| Contact Material | Brass | Termination Style | Solder Lug |
Product Info
| Style | Manual | Series | FX0 |
| Fuse Size | 5mm x 20mm | Fuse Type | Cartridge |
| Number of Circuits | 1 | Number of Batteries Included | :1 |
| For Use With/Related Products | 5mm x 20mm | ||
Environmental
| Operating Temperature | - 20 C to + 85 C | ||
