SF-0603F500-2
| Manufacturer | |
| Description | Fuses 5.00A 32V Fuse Fast Acting Fuse Chip Fast Acting 5A 32V SMD Solder Pad 0603 T/R FUSE FAST 32VDC 5A 0603 Bourns 5A F Surface Mount Fuse, 32V dc Surface Mount Fuses 5A Slow Blow SinglFuse Fuse Chip 5A 32V Fast 2-Pin Solder Pad Surface Mount T/R FUSE, 5A, 32VDC, SMD, FAST ACTING, FULL REEL FUSE, 5A, 32VDC, SMD, FAST ACTING FuseSMD06035AF SMD Fuse 5 A fast-blow,SinglFuse™, SF-0603F500-2, Bourns Bourns 5A 表面贴装熔断器, F熔断速度, 32 V 直流 |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Surface Mount Fuses | Other Names | SF-0603F500-2CT |
| Product Category | Fuses | Standard Package | 5,000 |
| Factory Pack Quantity | 10000 | ||
Compliance
| RoHS | RoHS Compliant By Exemption | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 85361010 |
| Approval Agency | UL | ||
Electrical
| Resistance | 12 mOhms | Melting I2t | 0.433 |
| Response Time | Fast | Voltage Rating | 32 V |
| Frequency - Max | F | Interrupt Output | 50 Amps |
| DC Cold Resistance | 0.012 Ohm | Current Rating (Max) | 5 A |
| Contact Voltage (Max) | :32V | Voltage - Input (Min) | 50 A |
| Blowout Characteristic | :Fast Acting | Voltage - Supply (Min) | 50A |
Mechanical
| Depth | :0.8mm | Width | 0.8 mm |
| Height | 0.45mm | Length | 1.6mm |
| Weight | 0 | Packaging | Reel |
| Body Material | Ceramic | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Package / Case | 0.45 mm |
| Length - Overall | 1.6 | Material - Blade | Tin Plated Copper/Nickel |
| Size / Dimension | 1.6 mm L x 0.8 mm W | Termination Style | SMD/SMT |
| Number of Contacts | 2 | ||
Product Info
| Type | SinglFuse Fast Acting Surface Mount Fuse | Series | SF-0603F |
| Fuse Size | 0603 (1608 metric) | Fuse Type | Fast Blow |
| Product Type | Surface Mount Fuse | ||
Environmental
| Must Operate | Fast | Operating Temperature | - 20 C to + 120 C |
