CDSOD323-T05C
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | CDSOD323-T05CCT | Part # Aliases | CDS0D323-T05C |
| Product Category | TVS Diodes - Transient Voltage Suppressors | Standard Package | Tape & Reel |
| Factory Pack Quantity | 3000 | Standard Package Name | SOD-323 |
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (16-Dec-2013) |
| EU RoHS | Compliant | Tariff No | 85411000 |
| Rad Hardened | No | ESD Protection | ±30@Air Gap/±30@Contact Disc |
Electrical
| Capacitance | 1(Typ) pF | TVS Polarity | :Bidirectional |
| Voltage Rating | 5 V | Current - Surge | 17 A |
| Voltage - Supply | 5V | Current - Leakage | 5uA |
| Voltage - Working | 5V | Number of Elements | 1 |
| Power - Peak Pulse | 350W | Voltage - Clamping | 9.8 V |
| Current - Trip (It) | 1 mA | Diode Configuration | :SOD-323 |
| Voltage - Breakdown | 6V | Power Line Protection | No |
| Bidirectional Channels | 1 | Voltage - Supply (Min) | 5 V |
| Capacitance @ Frequency | 3pF @ 1MHz | Current - Peak Pulse (8/20us) | 17 A |
| Current - Reverse Leakage @ Vr | 5 uA | Current - Peak Pulse (10/1000us) | 17A (8/20µs) |
| Voltage - Reverse Standoff (Typ) | 5 V | ||
Mechanical
| Depth | 1.45(Max) mm | Height | 1 mm |
| Weight | 0.000005 | Packaging | Tape & Reel (TR) |
| Mounting Type | Surface Mount | Mounting Style | Surface Mount |
| Number of Pins | :2 | Package / Case | SC-76, SOD-323 |
| Locking Feature | TVS | Material Finish | :MSL 1 - Unlimited |
| Length - Overall | 1.9(Max) mm | Package Quantity | SOD-323 |
| Size / Dimension | 1.45 mm W x 1.9 mm L x 1 mm H | Termination Style | SMD/SMT |
| Number of Positions | 2 | Supplier Device Package | SOD-323 |
Product Info
| Type | TVS | Polarity | Bidirectional |
| Applications | General Purpose | Configuration | Single |
| Port Direction | Bi-Directional | ||
Environmental
| Operating Temperature | -55 °C | Operating Temperature - Junction | 150C |
