1785B
| Manufacturer | |
| Description | Bench Top Power Supplies 0-18V 0-5A DIGITAL W/RS 232 INTERFACE POWER SUPPLY DGTL PROGRAM 0-18V PowerSupply,Programmable;0to18V;0to5A;ltlt=gt=1mV(RMS);Digital |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | BK1785B | Part # Aliases | EXD |
| Product Category | Bench Top Power Supplies | Standard Package | 1 |
Compliance
| RoHS | RoHS Compliant By Exemption | ||
Electrical
| Ripple | 3mV p-p, 1mV rms | Display Type | VFD |
| Voltage Rating | 110 VAC to 220 VAC | Current - Output | 0 ~ 5A |
| Voltage - Supply | 110VAC, 220VAC | Number of Outputs | 1 |
| Voltage - Input (Min) | 0 ~ 18VDC | Current Regulation - Line | 0.1% + 2mA |
| Current Regulation - Load | 0.1% + 2mA | Voltage Regulation - Line | 0.01% + 3mV |
| Voltage Regulation - Load | 0.01% + 3mV | Current - Output / Channel | 5 A |
| Accuracy - Voltmeter; Ammeter | 0.05% + 15mV | ||
Mechanical
| Weight | 13 lbs (5.9kg) | Cable Type | Detachable Power Cord Included |
| Size / Dimension | 15.000" L x 10.000" W x 4.160" H (381.00mm x 254.00mm x 105.66mm) | ||
Product Info
| Type | Bench (AC to DC) | Features | Programmable, RS232 Port |
| Number of Characters | 10 | ||
Documents & Media
PDF Document
