1715A
| Manufacturer | |
| Description | Bench Top Power Supplies DC (0-60V 0-2A) POWER SUPPLY 60V 2A DIGITAL PowerSupply;SingleOutputDCTypeofPowerSupply;0to60V;0to2A;210W |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | BK1715A | Part # Aliases | EXD |
| Product Category | Bench Top Power Supplies | Standard Package | 1 |
Compliance
| RoHS | RoHS Compliant By Exemption | ||
Electrical
| Ripple | 1mV rms | Power - Max | 210W |
| Display Type | LED | Voltage Rating | 120 VAC, 220 VAC, 230 VAC, 240 VAC Selectable |
| Current - Output | 0 ~ 2A | Voltage - Supply | 120VAC |
| Number of Outputs | 1 | Power Supply Type | SingleOutputDC |
| Voltage - Input (Min) | 0 ~ 60VDC | Current Regulation - Line | 0.2% + 3mA |
| Current Regulation - Load | 0.2% + 3mA | Voltage Regulation - Line | 0.01% + 3mV |
| Voltage Regulation - Load | 0.01% + 3mV | Current - Output / Channel | 2 A |
| Accuracy - Voltmeter; Ammeter | 0.5% + 9 digits | ||
Mechanical
| Weight | 12 lbs (5.4kg) | Cable Type | Detachable Power Cord Included |
| Size / Dimension | 12.500" L x 5.500" W x 6.200" H (317.50mm x 139.70mm x 157.48mm) | ||
Product Info
| Type | Bench (AC to DC) | Features | Constant Current and Constant Voltage Indicators |
| Meter Type | 4-DigitLED | Manufacturer | BK Precision |
| Product Type | Dc Power Supply | Number of Characters | 4 (2) |
Environmental
| Operating Temperature | 0to+40°C | ||
