1693
| Manufacturer | |
| Description | PWR SUPP 1-15V 60A W/REMOTE SENS Bench Top Power Supplies Switch DC Pwr Supply 1-60V, 15A w/Sense HighCurrentSwitchingDCPowerSupply,1-15V,60Amps |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | BK1693 | Product Category | Bench Top Power Supplies |
| Standard Package | 1 | ||
Compliance
| RoHS | RoHS Compliant By Exemption | ||
Electrical
| Ripple | 4mV p-p | Display Type | LED |
| Power (Watts) | 900W | Voltage Rating | 100 VAC to 240 VAC |
| Current - Output | 60A | Voltage - Supply | 100 ~ 240VAC |
| Number of Outputs | 1 | Voltage - Input (Min) | 1 ~ 15VDC |
| Voltage Regulation - Line | 0.05% + 3mV | Voltage Regulation - Load | 0.1% + 5mV |
| Current - Output / Channel | 60 A | Accuracy - Voltmeter; Ammeter | 1% + 1 count |
Mechanical
| Weight | 13 lbs (5.9kg) | Cable Type | North American Power Cord Included |
| Size / Dimension | 14.170" L x 8.660" W x 4.330" H (359.92mm x 219.96mm x 109.98mm) | ||
Product Info
| Type | Bench (AC to DC) | Features | Adjustable or Fixed Selection Switch |
| Number of Characters | 3 (2) | ||
