1671A
| Manufacturer | |
| Description | Bench Top Power Supplies Triple Output DC POWER SUPPLY 30V 5A TRPL-OUT AC/DC Power Supply Triple-OUT 0V to 30V/12V/5V 5A/0.5A/0.5A PowerSupply,DC;TripleOutput;108to132VACVi;350W;0to30VDCVo;0to5A;8.5In |
| Category |
对参数有疑问？问 AI 助手
Business
| Part # Aliases | EXD | Product Category | Bench Top Power Supplies |
| Standard Package | 1 | ||
Compliance
| RoHS | RoHS Compliant By Exemption | ||
Electrical
| Output | 5VDC@0.5A,12VDC@0.5A,30VDC@5A | Ripple | 1mV rms |
| Operation | Linear | Power - Max | 350W |
| Display Type | LED | Load Current | 10mA |
| Power - Output | 265W | Voltage Rating | 115 VAC, 230 VAC Selectable |
| Current - Output | 0 ~ 5A | Voltage - Supply | 108 ~ 132VAC |
| Number of Outputs | 3 | Voltage - Output 3 | 5 VDC |
| Voltage - Input (Min) | 0 ~ 30VDC, 12VDC, 5VDC | Current Regulation - Line | 0.4% + 10mA |
| Current Regulation - Load | 0.4% + 10mA | Voltage Regulation - Line | 0.05% + 10mV |
| Voltage Regulation - Load | 0.05% + 10mV | Current - Output / Channel | 500 mA |
| Accuracy - Voltmeter; Ammeter | 1% + 2 digits | ||
Mechanical
| Width | 8.5in. | Weight | 14 lbs (6.4kg) |
| Cable Type | Detachable Power Cord Included | Mounting Style | Panel |
| Primary Material | AC-DC | Size / Dimension | 11.500" L x 8.500" W x 4.900" H (292.10mm x 215.90mm x 124.46mm) |
Product Info
| Type | Bench (AC to DC) | Features | Shortcircuitandreversepolarityprotection,ULcertified,Constantvoltage,1-YearWarranty |
| Configuration | Enclosed | Number of Characters | 3 (2) |
Environmental
| Operating Temperature | 0to+40°C | ||
Documents & Media
PDF Document
