NOSE337M006R0080
| Manufacturer | |
| Description | Cap Niobium 330uF 6.3V 20% (7.3 X 4.3 X 4.1mm) SMD 0.08 Ohm 125°C T/R Niobium Oxide Capacitors 6.3volts 330uF 20% ESR=80mOhms CAP NIOB OXIDE 330UF 6.3V 2917 CAPACITOR, CASE E, 330UF, 6.3V Capacitor: niobium; OxiCap; 330uF; 6.3V; Case: E; ESR:80mΩ; SMD; ±20% |
| Category |
对参数有疑问？问 AI 助手
Business
| MOQ | 400 | Product | Niobium Oxide Capacitors |
| Tradename | Oxicap | Unit Pack | 400 |
| Other Names | 478-3251-2 | Product Category | Niobium Oxide Capacitors |
| Standard Package | Tape & Reel | Factory Pack Quantity | 400 |
Compliance
| RoHS | RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| Tariff No | 85322400 | ||
Electrical
| ESR | 80mΩ | Voltage | 6.3 Vdc |
| Tolerance | 20 % | Capacitance | 330 uF |
| Voltage Rating | 6.3 V | Current - Leakage | 39.6 uA |
| Capacitance - Input | :2917 [7343 Metric] | Capacitance @ Vr, F | niobium |
| Voltage - Supply (Min) | 6.3V | Capacitance Ratio Condition | OxiCap |
| Ripple Current @ High Frequency | 1.573 A | ESR (Equivalent Series Resistance) | 0.08 Ohm |
Mechanical
| Depth | 4.3 mm | Width | 4.3 mm |
| Height | 4.1 mm | Length | :7.3mm |
| Weight | 0.000399 | Packaging | Reel |
| Construction | Flat | Mounting Type | Surface Mount |
| Reel Capacity | :400 | Terminal Type | :Surface Mount (SMD, SMT) |
| Number of Pins | :2 | Package / Case | 7343-43 |
| Length - Overall | 7.3 mm | Package Quantity | 400 |
| Size / Dimension | 4.3 mm W x 7.3 mm L x 4.3 mm H | Tape Width - Max | :8mm |
| Termination Style | SMD/SMT | Height - Seated (Max) | 0.169" (4.30mm) |
Product Info
| Spg | 400 | Type | Oxicap Low ESR Series Niobium Oxide Capacitor |
| Series | NOS | Features | Low ESR |
| Number of Units | 1 | Manufacturer Size Code | E |
Environmental
| Operating Temperature | -55 to 125 °C | Power Dissipation @ Temperature Rise | 12% |
