KBS-20DB-4P-0
| Category |
对参数有疑问？问 AI 助手
Business
| Product Category | Audio Indicators & Alerts | Standard Package | 500 |
| Factory Pack Quantity | 500 | ||
Compliance
| RoHS | RoHS Compliant | EU RoHS | Compliant |
Electrical
| Frequency | 4.096kHz | Input Type | peak-peak Signal |
| Voltage Rating | 10Vp-p | Frequency - Max | 4096(Typ) |
| Driver Circuitry | Transducer, Externally Driven | Capacitance @ Frequency | 14000pF @ 4.096kHz |
| Sound Pressure Level (SPL) | 77dB @ 10V, 30cm | ||
Mechanical
| Height | 6.5 | Diameter | 22 |
| Packaging | Bulk | Termination | Pin |
| Mounting Type | Through Hole | Size / Dimension | Circular - 22.00mm Dia x 6.50mm H |
| Termination Style | Wire | Number of Contacts | 2 |
Product Info
| Type | Buzzer | Washable | No |
| Technology | Piezo | ||
Environmental
| Mechanical Life | Obsolete | ||
Documents & Media
PDF Document
PDF Document
Sourcing & traceability
- Datasheet
- KBS Series Piezo Buzzers
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
