FFLI6U0157K--
| Manufacturer | |
| Description | Film Capacitors 1200v 150uF Male Threaded CAP FILM 150UF 1.2KVDC SCREW CAPACITOR PP FILM PP, 150UF, 10%, 1.15KV, Capacitor; PolyproMetallized; Cap150uF; Tol10%; Vol-Rtg1150V; ScrewTerm; Male |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | Power Electronics Capacitors | Standard Package | 16 |
Compliance
| RoHS | RoHS Compliant | Tariff No | 85322500 |
Electrical
| Tolerance | 10 % | Capacitance | 150 uF |
| Range deg/s | :AVX - FFLI Series | Voltage Rating | 1.15 kV |
| Capacitance - Input | :Can | ESR (Equivalent Series Resistance) | 5 mOhms |
Mechanical
| Weight | 0 | Diameter | 75 mm |
| Packaging | Bulk | Termination | Screw Terminals |
| Lead Spacing | 1.260" (32.00mm) | Mounting Type | Chassis, Stud Mount |
| Package / Case | 105 mm | Material - Core | Polypropylene Metallized |
| Size / Dimension | 2.953" Dia (75.00mm) | Termination Style | Screw |
| Dielectric Material | Polypropylene (PP) | Height - Seated (Max) | 4.213" (107.00mm) |
Product Info
| Type | Capacitors for Power Electronics | Series | FFLI |
| Features | DC Filtering | Applications | General Purpose |
| Product Type | Power | ||
Environmental
| Operating Temperature | - 40 C to + 95 C | ||
