ADUC847BSZ32-5
| Manufacturer | |
| Description | MCU 8-bit ADuC8xx 8052 CISC 62KB Flash 3.3V/5V 52-Pin MQFP IC MCU 8BIT 32KB FLASH 52MQFP ADUC847BSZ32-5, 8 bit Microcontroller 8052 12.58MHz 4, 62kb Flash, 2304B RAM, I2C SPI 52-Pin MQFP 8-bit Microcontrollers - MCU Microcnvtr w/ Built In 24B ADC & 12B DAC 10 CHANNEL 24 BIT ADC + FLASH 8 BIT UP |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | ADUC847BSZ325 | Standard Package | Trays |
| Factory Pack Quantity | 96 | Standard Package Name | QFP |
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 85423190 |
| Approval Agency | No | ||
Electrical
| Speed | 12.85 MHz | Timer | 3 x 16 bit |
| RAM Size | 2.25 KB | Core Size | 8-Bit |
| Core Type | 8052 | Interface | I2C/SPI/UART |
| Clock Rate | 12 MHz | Resolution | 16bit |
| EEPROM Size | 4K x 8 | Memory Size | 2304 B |
| Number of I/O | 24 | Number of Bits | 24 |
| Voltage Rating | 2.7 → 5.25 V | Watchdog Timer | 1 |
| Clock Frequency | :12.58MHz | Data Converters | A/D 10x24b; D/A 1x12b, 2x16b |
| Frequency - Max | 12.58MHz | Number of DAC's | 1 |
| Oscillator Type | Internal | Serial Protocol | 1 |
| Voltage - Supply | 3.3|5 V | Resolution (Bits) | 24bit |
| Number of Channels | 0 | Program Memory Size | 62 KB |
| Program Memory Type | Flash | Number of ADCs / DACs | 10 |
| Voltage - Supply (Min) | 3.6|5.25 | Frequency (Center/Band) | 16bit |
| Number of Bits per Element | 12 | Voltage - Supply (Vcc/Vdd) | 4.75 V ~ 5.25 V |
Mechanical
| Width | 10mm | Height | 2mm |
| Length | 10mm | Weight | 0.00001 |
| Packaging | Tray | Lead Style | Gull-wing |
| Mounting Type | Surface Mount | Mounting Style | SMD/SMT |
| Number of Pins | :52 | Package / Case | 52MQFP |
| Package Cooled | MQFP | Material Finish | :MSL 3 - 168 hours |
| Length - Overall | 10 | Package Quantity | MQFP |
| Size / Dimension | 10 x 10 x 2mm | Number of Positions | 52 |
| Shell Size - Insert | 2 | Number of Cores/Bus Width | 8 Bit |
| Pulse Width Distortion (Max) | 6 x 16 bit | ||
Product Info
| SPI | 1 | USB | 0 |
| Series | ADUC847 | Protocol | 1 |
| On-Chip RAM | 10-chx24-bit | Peripherals | POR, PSM, PWM, Temp Sensor, WDT |
| Architecture | CISC | Connectivity | I²C, SPI, UART/USART |
| Core Processor | 8052 | Number of Timers | 3 |
| Controller Series | :(8052) ADUC | RF Family/Standard | ADuC8xx |
| DigiKey Programmable | Yes | Printed Circuit Board | 52 |
Environmental
| Operating Temperature | -40 to 125 °C | ||
