ADUC845BCPZ62-3
| Manufacturer | |
| Description | MCU 8-bit ADuC8xx 8052 CISC 62KB Flash 3.3V/5V 56-Pin LFCSP EP IC MCU 8BIT 62KB FLASH 56LFCSP 8-bit Microcontrollers - MCU Microcnvtr w/ Built In 24B ADC & 12B DAC |
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | Trays | Factory Pack Quantity | 260 |
| Standard Package Name | LFCSP | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
| Approval Agency | No | ||
Electrical
| Speed | 12.85 MHz | RAM Size | 2.25 KB |
| Core Size | 8-Bit | Core Type | 8052 |
| Interface | I2C/SPI/UART | Clock Rate | 12 MHz |
| EEPROM Size | 4K x 8 | Memory Size | 2.25 kB |
| Number of I/O | 24 | Number of Bits | 24/24 |
| Voltage Rating | 2.7|4.75 | Watchdog Timer | 1 |
| Data Converters | A/D 10x24b; D/A 1x12b, 2x16b | Number of DAC's | 1 |
| Oscillator Type | Internal | Serial Protocol | 1 |
| Voltage - Supply | 3.3|5 V | Resolution (Bits) | 24 bit |
| Program Memory Size | 62 KB | Program Memory Type | Flash |
| Number of ADCs / DACs | 10/10 | Voltage - Supply (Min) | 3.6|5.25 |
| Number of Counter/Timers | 3 Timer | Number of Bits per Element | 12 |
| Voltage - Supply (Vcc/Vdd) | 2.7 V ~ 3.6 V | ||
Mechanical
| Width | 8 | Height | 0.83 mm |
| Length | 8 mm | Packaging | Tray |
| Lead Style | No Lead | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Package / Case | 56LFCSP EP |
| Length - Overall | 8 | Package Quantity | LFCSP EP |
| Number of Positions | 56 | Shell Size - Insert | 0.83 |
| Number of Cores/Bus Width | 8 Bit | ||
Product Info
| SPI | 1 | Series | ADUC845 |
| Protocol | 1 | On-Chip RAM | 2(10-chx24-bit) |
| Peripherals | POR, PSM, PWM, Temp Sensor, WDT | Architecture | CISC |
| Connectivity | I²C, SPI, UART/USART | Manufacturer | Analog Devices |
| Core Processor | 8052 | Number of Timers | 3 |
| RF Family/Standard | ADuC8xx | DigiKey Programmable | Yes |
| Printed Circuit Board | 56 | Number of Inputs and Type | 34 I/O |
Environmental
| Operating Temperature | -40 to 85 °C | ||
