ADSP-21369BSWZ-1A
| Manufacturer | |
| Description | DSP Floating-Point 32-Bit/40-Bit 266MHz 266MIPS 208-Pin LQFP EP IC DSP 32BIT 266MHZ 208LQFP Digital Signal Processors & Controllers - DSP, DSC High-Perf 32B Floating-Point DSP, 32BIT, SHARC, 266MHZ, 208LQFP |
| Category |
对参数有疑问？问 AI 助手
Business
| Product | DSPs | Tradename | SHARC |
| Other Names | ADSP21369BSWZ1A | Standard Package | Trays |
| Factory Pack Quantity | 36 | Standard Package Name | QFP |
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 84718000 |
| Rad Hardened | No | ||
Electrical
| Speed | 266 MHz | RAM Size | 256 KB |
| Core Size | 32/40 b | Core Type | SHARC |
| Frequency | :266MHz | Interface | DAI, DPI |
| Clock Rate | 266 MIPS | Memory Size | 256 KB |
| Number of I/O | 16 | Voltage - I/O | 3.30V |
| Voltage - Core | 1.20V | Voltage Rating | 1.14|3.13 |
| Clock Frequency | 266 MHz | Voltage - Supply | 1.2|3.3 V |
| Non-Volatile Memory | ROM (768 kB) | Program Memory Size | 768 KB |
| Program Memory Type | ROM | Voltage - Supply (Min) | 1.14/3.13 V |
Mechanical
| Weight | 0.00035 | Packaging | Tray |
| Lead Style | Gull-wing | Termination | :SMD |
| Mounting Type | Surface Mount | Mounting Style | SMD/SMT |
| Number of Pins | :208 | Package / Case | 208LQFP EP |
| Package Cooled | LQFP EP | Material Finish | :- |
| Package Quantity | LQFP EP | Number of Positions | 208 |
| Supplier Device Package | 208-LQFP-EP (28x28) | Number of Cores/Bus Width | 32|40 Bit |
Product Info
| Type | Floating Point | Format | Floating Point |
| Series | ADSP-21369 | Base Unit | :21369 |
| On-Chip RAM | 256kB | Architecture | Super Harvard |
| Programmable | Yes | Number Format | Floating-Point |
| Number of Timers | 3 | Other Specifications | 266 |
Environmental
| Operating Temperature | -40°C ~ 85°C | Operating Temperature - Junction | 85C |
