ADP1864AUJZ-R7
| Manufacturer | |
| Description | DC DC Cntrlr Single-OUT Step Down 3.15V to 14V Input 6-Pin TSOT T/R IC REG CTRLR BUCK PWM TSOT23-6 DC-DC Controller 580kHz Current TSOT6 Switching Controllers Constant Freq Crnt Mode Step-Down 03-5 AMP NON SYNCHRONOUS BUCK CONTROLLER Analog Devices 直流-直流降压控制器, 5A, 14 V 降压, 650 kHz, 6针 TSOT封装 |
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | ADP1864AUJZ-R7CT | Standard Package | Tape & Reel |
| Standard Package Name | SOT-23 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| EU RoHS | Compliant | Tariff No | 85423990 |
| Rad Hardened | No | ||
Electrical
| PWM Type | Current Mode | Duty Cycle | 100% |
| Cuk Converter | No | Buck Converter | Yes |
| Isolated Power | No | Voltage Rating | 0.8 to 14 V |
| Boost Converter | No | Frequency - Max | 650kHz |
| Current - Output | 5A | Voltage - Supply | 3.15 to 14 V |
| Doubler Converter | No | Flyback Converter | No |
| Number of Outputs | 1 | Divider/Multiplier | No |
| Regulator Topology | Step Down | Inverting Converter | No |
| Frequency - Switching | 650 kHz | Voltage - Input (Min) | :14V |
| Voltage - Output (Max) | 14 V | Voltage - Output (Min/Fixed) | 0.8 V |
| Common Mode Transient Immunity (Min) | Industrial | ||
Mechanical
| Width | 1.6mm | Height | 0.9mm |
| Length | 2.9mm | Weight | 0.00001 |
| Packaging | Tape and Reel | Mounting Type | Surface Mount |
| Mounting Style | SMD/SMT | Number of Pins | :6 |
| Package / Case | 6TSOT | Package Cooled | TSOT |
| Material Finish | :MSL 3 - 168 hours | Length - Overall | 2.9 |
| Package Quantity | TSOT | Size / Dimension | 2.9 x 1.6 x 0.9mm |
| Number of Positions | 6 | Shell Size - Insert | 0.87 |
Product Info
| Type | Step Down | Series | ADP1864 |
| Shutdown | Yes | Topology | Buck |
| Controller Type | Buck Controller | Printed Circuit Board | 6 |
Environmental
| Operating Temperature | -40 to 125 °C | Operating Temperature - Junction | 125C |
